View DRC-12V60W1AZ product specification.
Delta
Electronics extends its Chrome DIN Rail Power Supply series with a 60W
product offering 12V output voltage. Delta’s Chrome DIN Rail Power
Supply series is designed for use in compact cabinets. This model (DRC-12V60W1AZ)
measures only 55.6mm thick and 91mm tall. The features include
overvoltage overvoltage, over temperature and overload protections. The
Chrome series provides Class II Double Isolation and are widely adopted
in home automation and Food & Beverages industries. The double
isolated input eliminates the need for Earth connection, thus, resulting
in very low leakage current.
DRC-12V60W1AZ offers universal AC input range and is certified to safety standard
according to IEC/EN/UL 60950-1 Information Technology Equipment (ITE)
and UL 508 Industrial Control Equipment (ICE) and is fully compliant
with RoHS Directive 2011/65/EU for environmental protection. NEC Class 2 and Limited Power Source (LPS) approvals are also available for the above model.
Highlights & Features
- Protection Class II, Double Isolation (No Earth connection is required)
- Universal AC input voltage without power de-rating
- Efficiency > 86.0% @ 115Vac & 230Vac
- NEC Class 2 / Limited Power Source (LPS) certified
- Overvoltage / Overcurrent / Over Temperature / Short Circuit Protections
AVAILABLE FOR SHIPMENT FROM DECEMBER 2013 ONWARDS.
New models are introduced on a regular basis. For more information or enquiries, please do not hesitate to contact your local Delta Electronics distributor or visit www.DeltaPSU.com.
