EUCO-200140GA

LED Driver

EUCO PRO Series

EUCO-200140GA

Output Voltage

75-190V

Output Power

200W

Output Current

0.5-1.4A

Input Voltage Range

176-305Vac

Dimensions (L x W x H)

220 x 68 x 37 mm

8.66” x 2.68” x 1.46”

Unit Weight

1.1 kg (2.43 lb)

Highlights & Features
  • Wind range constant current design
  • Universal AC input voltage from 220-240Vac
  • High efficiency up to 94%
  • Wide operating temperature range -40°C to +55°C
  • With IP66/IP67 protection from most outdoor applications
  • Build-in Active PFC and confirm to harmonic current IEC/EN 61000-3-2, Class C
  • Adjustable constant current level through programmable tool
  • Common mode 6kV and differential mode 6kV surge immunity
  • Suitable for Dry / Damp / Wet location
  • 0-10V dimming available
Applications


EUCO-200140GA
EUCO-200140GA

LED Driver

EUCO PRO Series

EUCO-200140GA

Highlights & Features
  • Wind range constant current design
  • Universal AC input voltage from 220-240Vac
  • High efficiency up to 94%
  • Wide operating temperature range -40°C to +55°C
  • With IP66/IP67 protection from most outdoor applications
  • Build-in Active PFC and confirm to harmonic current IEC/EN 61000-3-2, Class C
  • Adjustable constant current level through programmable tool
  • Common mode 6kV and differential mode 6kV surge immunity
  • Suitable for Dry / Damp / Wet location
  • 0-10V dimming available
Output Voltage

75-190V

Output Power

200W

Output Current

0.5-1.4A

Input Voltage Range

176-305Vac

Dimensions

220 x 68 x 37 mm

8.66” x 2.68” x 1.46”

Unit Weight

1.1 kg (2.43 lb)
