USCO-100140GA

LED Driver

USCO PRO Series

USCO-100140GA

Output Voltage

47-143V

Output Power

100W

Output Current

Input Voltage Range

99-305Vac

Dimensions (L x W x H)

174 x 63 x 37 mm

6.85” x 2.48” x 1.46”

Unit Weight

0.9 kg (1.98 lb)

Highlights & Features
  • Constant current design
  • Universal AC input voltage from 99-305Vac
  • High efficiency up to 95%
  • Wide operating temperature range -40oC ~ +60oC
  • With IP67 protection for most outdoor applications
  • Built-in Active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class C
  • Adjustable constant current level through program tool
  • Common mode 6kV and differential mode 6kV surge immunity
  • Suitable for Dry / Damp / Wet location
  • 5 years warranty
Tags
Applications


USCO-100140GA
USCO-100140GA
Enquiry

LED Driver

USCO PRO Series

USCO-100140GA

Highlights & Features
  • Constant current design
  • Universal AC input voltage from 99-305Vac
  • High efficiency up to 95%
  • Wide operating temperature range -40oC ~ +60oC
  • With IP67 protection for most outdoor applications
  • Built-in Active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class C
  • Adjustable constant current level through program tool
  • Common mode 6kV and differential mode 6kV surge immunity
  • Suitable for Dry / Damp / Wet location
  • 5 years warranty
Output Voltage

47-143V

Output Power

100W

Output Current

100W

Input Voltage Range

99-305Vac

Dimensions

174 x 63 x 37 mm

6.85” x 2.48” x 1.46”

Unit Weight

0.9 kg (1.98 lb)

Applications
Tags

Download

Download

Datasheet

Uploaded on 22-Apr-2020

Mechanical Drawing

Uploaded on 22-Apr-2020

.STP

Uploaded on 22-Apr-2020

CB

Uploaded on 22-Apr-2020

CE

Uploaded on 22-Apr-2020

ENEC

Uploaded on 22-Apr-2020

REACH

Uploaded on 22-Apr-2020

RoHS

Uploaded on 22-Apr-2020

UL

Uploaded on 22-Apr-2020

GUI Program

Uploaded on 29-May-2020

Tech Specs

Tech Specs
